Description
Description:
Horsepower & Torque: 365 Horsepower / 365 ft. lbs. Torque
Compression Ratio: 10.0:1
Aluminum Heads
Hydraulic Roller Cam
Hypereutectic Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Increased Deck Thickness and Strength Webbing
Priority Main Oiling
4.000″ Bore
4-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Rotating Assembly:
Cast Crankshaft
3.000″ Stroke
OEM Type 5.090″ Connecting Rods
Hypereutectic Pistons
50oz Externally Balanced
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – HP9009
60cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
190cc Intake / 60cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.533 Intake / .544 Exhaust Lift
215 Intake / 220 Exhaust Duration
@.050-114 Degree Lobe Separation
Ignition Timing:
34 Degrees Total at 3500 RPM
Also Includes:
Holley Street Warrior 600cfm Vacuum Secondary Carburetor w/ Electric Choke
Front Accessory Drive with A/C Compressor, Water Pump, Alternator and Power Steering Pump
Dual Plane, Satin Aluminum Intake Manifold
Distributor
Valve Covers
Dual/Rear Sump Oil Pan
Electric Fuel Pump Included
Thermostat and Thermostat Housing
Assembled with Complete 4R70W 4WD Ready – Automatic Trans Package:
Includes Electronic Transmission Controller
THROTTLE POSITION SENSOR NOT INCLUDED
Transmission Built to 650 HP
2200-2600 Stall Torque Converter
Flex Plate
Starter
4 Speed, Overdrive Transmission w/Lockup
Specifically Prepped for Dana 20 Transfer Case (1966-1976). Transfer case is NOT included
GEAR RATIOS
First: 2.84 :1.
Second: 1.55 :1.
Third: 1.00 :1.
Overdrive: 0.70 :1.
Reverse: 2.32 :1.
