Description
Description:
Horsepower & Torque: 541 Horsepower / 519ft. lbs. Torque
Compression Ratio: 10.0:1
Aluminum Heads
Hydraulic Roller Cam
Forged Crank
Forged Pistons
Block:
DART SHP Block Machined in the USA!
4-Bolt Main
4.125″ Bore
1-Piece Rear Main Seal
9.500 Deck Height
Rotating Assembly:
New Forged Crankshaft
4.000″ Stroke
Forged 6.250″ Connecting Rods
Forged Pistons
Internally Balanced
Cylinder Heads:
Aluminum Cylinder Heads
60cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
205cc Intake / 70cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.608 Intake / .608 Exhaust Lift
248 Intake / 258 Exhaust Duration
@.050-114 Degree Lobe Separation
Also Includes:
Ribbed 427 Cobra Aluminum Valve Covers
Holley 870 cfm Carburetor
Harmonic Balancer
Spark Plugs & Wires
Plug Wire Separators
Timing Cover
Powder Coated 9qt. Oil Pan
Thermostat and Thermostat Housing
Oil Filter
Fuel Pump
Accessory Drive with A/C Compressor, Water Pump, Alternator, and Power Steering Pump
Assembled with Complete 4R70W Automatic Transmission Package:
Includes Electronic Transmission Controller
Transmission built to 650 HP
2200-2600 Stall Torque Converter
Flex plate
Starter
4 Speed, Overdrive transmission w/Lockup
GEAR RATIOS
First: 2.84 :1.
Second: 1.55 :1.
Third: 1.00 :1.
Overdrive: 0.70 :1.
Reverse: 2.32 :1.
