Description
The Toyota 4Y is a 2.2-liter naturally aspirated petrol/gasoline inline-four engine from Toyota’s Y-series. It was developed primarily for commercial and utility vehicles such as the Toyota HiAce, HiAce Regius, Dyna, ToyoAce, and other market-specific applications.
The fuel-injected version is commonly identified as the 4Y-E / 4Y-EFI, depending on market and application. It should not be confused with the carbureted 4Y.
| Feature | 4Y Carbureted | 4Y EFI |
|---|---|---|
| Displacement | 2.2L | 2.2L |
| Cylinders | 4 | 4 |
| SOHC | Yes | Yes |
| Valves | 8 | 8 |
| Fuel system | Carburetor | Electronic injection |
| Turbo | No | No |
| Intercooler | No | No |
| Timing | Chain | Chain |
| Firing order | 1-3-4-2 | 1-3-4-2 |
| ECU | No/limited | Yes |
| Fuel injectors | No | Yes |
The Toyota 4Y EFI 2.2L is a 2,237 cc naturally aspirated four-cylinder petrol engine with a cast-iron block, aluminum SOHC 8-valve cylinder head, electronic fuel injection and timing chain. It was designed primarily for Toyota’s commercial vans, light trucks and utility vehicles, where durability, simple maintenance and reliable low-to-mid-range performance are more important than high horsepower.
